LC Low Clearance Hydraulic Torque Wrench
The LC Low Clearance Hydraulic Torque Wrench (also known as the LC Black Tool) is your go-to solution for projects with limited working radius,designed specifically for tight spaces, . Its Uniswivel feature provides a 360° rotatable and 120° foldable hose connection, making positioning effortless in almost any workspace. Trusted for over 30 years, the HTW delivers unmatched quality and durability, ensuring reliable performance for all your torque needs.
The Hydraulic Torque Wrenches with Low Clearance made by us are reliable, provide optimum torqueing power and are designed to exert torque on the toughest nuts with the following features:
- High nickel alloy steel internal components ensure long lasting moving parts.
- The rod engages in the first stroke thus removing any backlash.
- The Hydraulic Torque Wrenches use an Alloy steel high strength hydraulic cylinder designed to exert a torque as per application.
- The ratchet and pawl have a finer tooth for better engagement and torqueing.
- The quick connectors for the hydraulic lines are leak-resistant for safety even under pressure. This is an industry standard feature of the Tritorc hydraulic Torque wrench.
Below is the interactive Three Dimensional Model and the advantageous features that Tritorc's TSL series Square drive hydraulic torque wrenches provide.
Better End Cap Design
The End cap is designed to bear sufficient back pressure so that the piston operation is smooth and the forward force is applied properly by the bolt tightening equipment.
Wear Resistant Piston Rod
The piston rod is a hard chrome plated component, which makes sure that the rod seal does not wear out easily.
Easy Drive Installation
Quick push through drive for ease of fastening and unfastening of bolts.
Easy Access for Hydraulic Hoses
The hydraulic hose line coupler features a swivelling arm with 360 Deg. X 180 Deg. rotation ensures a high degree of freedom of movement even if the line is at full pressure.
Wear Resistant Bush
Self Lubricating low Nickel Bronze Drive Bush to protect body from wear.
Easy Reference Chart
A removable sheet metal chart with laser engraved torque rating in Nm and Ft Lbs. This makes for an easy to use hydraulic bolt tightening machine.
Hydraulic Torque Wrench Specification
There are many variations of Torque wrenches available, Select your required Torqueing tool from our Product Brochure or the chart below. When you ask for a quotation, be rest assured for the best hydraulic torque wrench price.
Model | Torque range(N.m) | A/F(mm) | Drive head weight(kg) | Working head weight(kg) | L | H1 | H2 | W1 | W2 |
2LOW | 232-2328 | 19-55 | 0.9 | 1.5 | 196 | 126 | 102 | 32 | 51 |
242-2414 | 60 | 0.9 | 1.5 | 196 | 129 | 105 | 32 | 51 | |
4LOW | 585-5858 | 34-65 | 1.7 | 3.4 | 258 | 163 | 136 | 42 | 66 |
647-6474 | 70-80 | 1.7 | 3.4 | 263 | 173 | 146 | 42 | 66 | |
8LOW | 1094-10941 | 41-95 | 3.0 | 6.3 | 300 | 192 | 168 | 53 | 83 |
1177-11774 | 100-105 | 3.1 | 6.3 | 311 | 201 | 177 | 53 | 83 | |
14LOW | 1852-18521 | 50-117 | 4.6 | 11.4 | 360 | 225 | 204 | 64 | 99 |
18LOW | 2695-26958 | 65-130 | 6.5 | 14.3 | 388 | 264 | 231 | 71 | 109 |
30LOW | 4188-41882 | 110-155 | 10.4 | 20.5 | 430 | 303 | 272 | 85 | 131 |
4459-44593 | 160-175 | 10.4 | 20.5 | 441 | 315 | 285 | 85 | 131 |
Features:
1. Max. working pressure up to 70Mpa, accuracy up to±3%
2. A total of six models from 232-44593Nm
3. 360°x180°and 360°x360°rotation hose connectors optional, used without limited space
4. Integrated lengthen design, longer arm, reliability enhanced
5. Aluminum and titanium alloy forming body, high strength, high toughness
6. New type anti - loose joints to ensure the oil flows smoothly
7. Anti-stop pawl design can prevent the wrench ratchet from reversing, higher work efficiency and torque accuracy
8. Hollow design, wrench directly acts on the nut, more accurate torque and lighter
